PTFE Mesh Conveyor Belt has such an excellent permeability that it can easily avoid exhausting heat and greatly improve the drying efficiency. Besides, it is also featured of high temperature resistance, non-adhesive, flame resistance and good flex fatigue. It’s even suitable for small wheels.

As PTFE Mesh Conveyor Belt is made by the ultra wide coating and dipping machine, its maximum width is up to 4,000mm. More details can be found at the below table.

PTFE Mesh Conveyor Belt is frequently used in drying machine for non-woven textile, textile printing, silk-printing and dyeing machine, shrinking machine for garment fabric, high-frequency and UV dryer, Oiling machine for paper glazing and waxing, plant engineering, It also used as conveyor belt for hot-air dryer, various of food baking, quick-frozen machines. Human beings still use it to separating sheet for hardboard.





Specifications :

Item No	Mesh Size	Material	Thickness	Weight	Temp Resistance	Max Width	Tensile Strength
HY-M001	1x1mm	Fiberglass	0.5mm	370g/m²	-140 to 360℃	4000mm	310/290N/cm
HY-M002	2x2mm	Fiberglass	0.7mm	450g/m²	-140 to 360℃	4000mm	350/310N/cm
HY-M003	4x4mm	Fiberglass	1.0mm	400g/m²	-140 to 360℃	4000mm	390/320N/cm
HY-M004	4x4mm	Fiberglass	1.0mm	450g/m²	-140 to 360℃	4000mm	390/320N/cm
HY-M007	4x4mm	Kevlar +Fiberglass	1.2mm	600g/m²	-140 to 360℃	4000mm	895/370N/cm
HY-M008	4x4mm	Fiberglass	1.0mm	500g/m²	-140 to 360℃	4000mm	395/370N/cm
HY-M010	4x4mm	Kevlar	1.0mm	500g/m²	-140 to 360℃	4000mm	900/600N/cm
HY-M012	4x4mm	Fiberglass	1.0mm	550g/m²	-140 to 360℃	4000mm	395/370N/cm
HY-M013	10x10mm	Fiberglass	1.2mm	450g/m²	-140 to 360℃	4000mm	360/300N/cm
HY-M014	0.5x1mm	Fiberglass	0.5mm	420g/m²	-140 to 360℃	4000mm	310/290N/cm
HY-M015	2x2.5mm	Fiberglass	0.9mm	600g/m²	-140 to 360℃	3000mm	390/320N/cm

  Mesh size: 1X1 mm，2X2mm，2*2.5mm, 4X4 mm,10X10mm and etc.
  Color: brown, black
  Material of the reinforced edge: PTFE film, PTFE fiberlgass fabric of 0.13mm, Kevlar fabric
  Joints：Bull-nose style, wall style and steel buckle style
